HVR®200

The Rosenberger Magnetic RJ45 is an innovative magnetic connector solution for Ethernet connections. Ideal for applications where frequent connections and disconnections are necessary, the unique self-mating and locking magnetic plug ensures the right connection every time – even in the most inaccessible places. Ease of cleaning of the RJ45 components, a robust housing and the plug-in processes using magnets make the product a highly durable solution. The usual features such as ease of termination, high number of mating cycles, and combined power and LAN connections all come as standard.

Electric Vehicles (LEV) including e-bikes, e-scooters and pedelecs as well as for UGVs and drones. Providing fast and reliable magnetic connection, these are particularly suited to data communication and power transmission of voltages up to 60 V and current loads up to 40 A. The magnetic locking and precision self-mating capability prevents any accidental or forced disconnection from damaging the connector or the LEV. Furthermore, the high tolerance pin and socket design permits a large number of mating cycles. The RoPD® connection system is ideal for many LEV connection applications – including battery changing and charging – where frequent connection and disconnection is required. The four data contacts and two power transmission pins make a hot-plug capability unnecessary as the data contacts activate the power following connection. For added flexibility the data contacts can be used as a BUS system with an additional supply voltage. Versions of the RoPD® system are also available for EnergyBus applications.

Rosenberger SLC (Spring Loaded Contacts) are suited to customized designs and frequencies up to 6 GHz. The product portfolio ensures impedance controlled SLC for transmission of RF signals across a diverse range of customized products and applications, such as backplane designs and those requiring a high degree of tolerance compensation between mating partners. Rosenberger SLC connectors and assemblies are therefore a perfect fit for specialized board-to-board applications, hybrid SLC solutions – with a combination of DC, RF signal transmission, power supply and fiber optical lines – as well as SLC cable connectors, board and panel mounted products.

Rosenberger HVR®50 connectors are available in straight and angled variants. The additional slide locking mechanism (CPA – Connector Position Assurance) prevents accidental disconnection. Despite their small size these connectors achieve a current capacity of approximately 60 A at 85 °C. HVR®50 connectors are mainly used in ancillary units such as electrical heating systems, air-conditioning units, DC/DC converters, and for charging batteries.
