TNC 50 ? / 75 ?

Rosenberger snap-in Mini-Coax inserts for Metral-chassis card edge connections offer modular high packing densities due to their extremely small size. As well as Multiport Mini-Coax are available in multiple 2, 4, 6 and 8 channel variants. Further benefits include fast, reliable connection, high data transmission rates, and superior electrical and mechanical stability.

Rosenberger provides a wide range of Multiport Mini-Coax connectors and cable assemblies for addressing the challenging technological demands of the semiconductor test equipment industry. For both 20 and 40 GHz applications, the extensive standard range comprises PCB connectors, purpose-designed plastic-housings and pre-assembled cable assembly sets. This ensures cable assembly configurations that precisely meet customer-specific test requirements. Board-to-board connections can be applied in very limited spaces with the advantages of coaxial shielding while a handy extraction tool ensures mating and demating can be done quickly and easily onsite. The cost-effective injection moulded housings for connection to one side of the PCB are available with 2, 4, 6 or 8 channels and allow the mixing of straight and right angle Mini-Coax cable pairs. Interface dimensions are based on Rosenberger standard Mini-Coax connectors.

The Rosenberger NEX10® connector system meets the existing and future infrastructure efficiency demands of small cell applications and 5G mobile networks. For frequencies up to 20 GHz, the new robust and highly compact NEX10® interface standard provides safe, easy and damage-free connection while minimizing interference from PIM (Passive Intermodulation). Screw-type and a push-pull locking mechanism are available. As a leading global manufacturer of RF products, Rosenberger is an active partner in the NEX10® consortium which is tasked with making the interface a worldwide IEC standard. Designed for upcoming 5G Networks.

Highly compact, HVR®420 connectors offer the highest current carrying capacity in the Rosenberger product portfolio. Even the 95 mm² variant safely enables current transmission of 420 A. Furthermore, the additional slide locking mechanism (CPA – Connector Position Assurance) prevents accidental disconnection. Typical applications include supercharging electric vehicle batteries up to 450 kWh.
