MCX

Rosenberger Rack Analyzers are designed to make PIM tests in production or test lab environments exceptionally modular, precise, and efficient. The budget-friendly broadband base unit concept offers maximum flexibility thanks to the option of connecting up to 11 filter units to one base unit. Integrated DTF measurement enables faster fault-finding by accurately pointing out the source of PIM. With the plug-and-play filter concept, intuitive software operation and easy-to-replace dust filters, it is possible to create a significant reduction in production downtime caused by changes in test frequencies or maintenance and servicing work.

Rosenberger offers a complete range of 50Ω coaxial cables from 1/4" to 1 5/8". The feeders provide best in-class electrical and mechanical performance: Low attenuation Low VSWR/RL CPR-rated Complete EMI shielding to minimize system interference Outstanding PIM performance High-power rating The cable construction is similar for all cable sizes: Inner conductor, foam dielectric, outer conductor and outer jacket. The cables are available as standard with either a PE jacket for outdoor installations or in a flame retardant and halogen-free version to comply with indoor requirements for health and safety, IEC 60332 and CPR-EN 50575.

Rosenberger WSMP®PCB connectors, bullets and cable assemblies are extremely compact and capable of handling frequencies up to 100 GHz. WSMP® connectors are about 45 % smaller than standard SMP connectors for allowing high packing density. Featuring a push-on coupling mechanism and enabling a minimum board-to-board distance of 3.05 mm, they are optimized for customer-specific footprints and layout recommendations.
