Lehimsiz PCB Konnektörleri

For ensuring fast and easy connection Rosenberger RoDI® connectors comprise five contacts and a magnetic self-mating locking mechanism. They are ideally suited to diagnostic and data transfer in building services, industrial control and bus systems, even for use in harsh environments.

Rosenberger provides a wide range of Multiport Mini-Coax connectors and cable assemblies for addressing the challenging technological demands of the semiconductor test equipment industry. For both 20 and 40 GHz applications, the extensive standard range comprises PCB connectors, purpose-designed plastic-housings and pre-assembled cable assembly sets. This ensures cable assembly configurations that precisely meet customer-specific test requirements. Board-to-board connections can be applied in very limited spaces with the advantages of coaxial shielding while a handy extraction tool ensures mating and demating can be done quickly and easily onsite. The cost-effective injection moulded housings for connection to one side of the PCB are available with 2, 4, 6 or 8 channels and allow the mixing of straight and right angle Mini-Coax cable pairs. Interface dimensions are based on Rosenberger standard Mini-Coax connectors.

Rosenberger offers a wide test port portfolio of cable assemblies, ruggedized adaptors and an interchangeable port system for vector network analyzers (VNA) up to 90 GHz: Test port cables providing outstanding phase and amplitude stability are also available as sets containing two cables with a standard length of 60 cm each. The range is optimized for frequencies up to 12 GHz, 18 GHz, 26.5 GHz, 40 GHz, 50 GHz, 70 GHz and 90 GHz. VNA test port cables are also available as cable sets, containing two cables of 600 mm standard length, and are supplied in high-quality wooden boxes. Test port adaptors are designed to connect directly to the VNA test port via a ruggedized coupling nut. They are available in the RPC-3.50, RPC-2.92, RPC-2.40, RPC-1.85 and RPC-1.35 connector series. Available as "in series" and "inter series" versions, their ruggedized construction ensures reliable protection of VNA test ports and reduces mechanical abrasion to a minimum. Interchangeable port connectors are designed for test equipment applications using test ports that will be continually mated and re-mated. This has been achieved by the development of an interchangeable port connector system featuring a panel mounting half and an innovative neutral interface, allowing a high number of mating cycles without causing possible damage to the equipment device interface.

Continuous expansion and consolidation of LTE and 5G networks require future-proof and versatile connectivity solutions between the BBU/PSU and the RRHs. Rosenberger’s focus is to offer Plug & Play FTTA/PTTA solutions that provide a Neutral Point of Interface to ensure efficient and cost-effective installations, upgrades, swaps and addition of new technologies.
