Çok Bantlı Çözümler

The 90R4 is a mass fusion splicer capable of splicing up to 4 fiber ribbon cables simultaneously. In previous mass fusion splicer models, the v-grooves could become dirty over time due to debris and glass deposits from splicing accumulating in the v-grooves. Which in turn, could lead to fibre offsets and high losses if they were not regularly cleaned which added to the overall process time. The 90R4 comes with a first of its kind, innovative user replaceable V-groove assembly which makes this issue a thing of the past and is supplied as standard equipment with the 90R4 kit. This new V-groove assembly can be quickly and easily fitted in the field, minimizing downtime and maximising productivity. also making use of Active Blade Management Technology, which now can connect to two CT50 cleavers simultaneously.

The Rosenberger portable and multifunctional broadband PIM Site Analyzer alpha provides the best alternative of performing the most precise and efficient PIM tests on site. The PIM Site Analyzer alpha consists of a single master unit with band-specific, interchangeable filter units, since the form factor of the filter units is the same. Take out one filter unit, e.g., 900 MHz, and replace with another filter unit, e.g., 1800 MHz, without any calibration of the filter unit, potential adaptors, test cable, or operational mode(s). Future-proof plug and play concept covering 700 to 2700 MHz.

Rosenberger’s comprehensive portfolio of cost-effective, high-quality and precision products enables a broad spectrum of industrial test & measurement applications for active or passive devices. While several types of network analyzers (NAs) have become increasingly important in the development of microwave circuits and systems in industrial measurement applications, vector network analyzers (VNAs) are particularly useful. This is due to their calibration capability and the ability to measure more parameters. Rosenberger develops and offers a wide range of metrology kits for a variety of standard and precision interfaces when performing calibration, verification and traceability, as well as gauges and gauge kits for vector network analyzers (VNAs).

The Rosenberger HPK system can achieve 275 A at 85 °C up to 1000 V. With their excellent vibration and current capacity performance the HPK connectors are well-suited to typical high-voltage electric vehicle applications such as the connection between battery, inverter and PDU. The range includes 1-, 2-, or 3-pole connectors which for maximum flexibility can be used with copper or aluminum cables in four different cable cross sections. Straight and angled cable couplers as well as corresponding headers are available, either with or without HVIL (high-voltage interlock).
