Optical Fiber Temporary Jointing Device TJ series TJ-01 / TJ-02 / TJ-03

AFL’s LZM-100 LAZERMaster is a glass processing and splicing system that uses a CO2 laser heat source rather than electrodes, ensuring repeatable performance and low maintenance, and eliminating electrode or filament maintenance and instability. Splicing or adiabatic tapering (to create mode field adapters or pump combiners) can be performed with glass diameters of 2.3 mm or less. The high resolution optical analysis system works in conjunction with on-board firmware for fully automatic splicing, tapering and other glass shaping processes.

The APM-102 perform all the steps required to prepare optical fibers before splicing – automatically and with high consistency. This includes stripping the fiber without degrading fiber quality, cleaning fiber with alcohol to remove coating residue, and cleaving consistently at a right angle to the fiber axis. The entire process is complete in as little as 23 seconds.

The JS-02-900 is designed for stripping single count of silica optical fiber. The JS-02-900 accepts the FH-40 series and FH-100 series Fiber Holder System.

Nyfors product. The AutoCleaver S1™ senses the edge of the coating to automatically adjust the bare fiber length after cleaving. This feature is valuable when a specific and accurate bare fiber length is required. The requested bare fiber length is specified by the customer at order and can be fine tuned by software between 0 and 500 μm.
