SMP Infinity

Rosenberger provides a wide product range of solderless PCB connectors for challenging test & measure­ment demands and for frequencies up to 110 GHz. These PCB connectors can easily be assembled by using screws. Standard screws are included, optional screws for thicker PCBs are available on request.

Rosenberger provides a wide range of Multiport Mini-Coax connectors and cable assemblies for addressing the challenging technological demands of the semiconductor test equipment industry. For both 20 and 40 GHz applications, the extensive standard range comprises PCB connectors, purpose-designed plastic-housings and pre-assembled cable assembly sets. This ensures cable assembly configurations that precisely meet customer-specific test requirements. Board-to-board connections can be applied in very limited spaces with the advantages of coaxial shielding while a handy extraction tool ensures mating and demating can be done quickly and easily onsite. The cost-effective injection moulded housings for connection to one side of the PCB are available with 2, 4, 6 or 8 channels and allow the mixing of straight and right angle Mini-Coax cable pairs. Interface dimensions are based on Rosenberger standard Mini-Coax connectors.

Rosenberger TNC* coaxial connectors are based on BNC connector characteristics and interface dimensions. However, the screw-on locking mechanism enables reliable, quick and easy interconnection while also allowing their use under higher environmental loads compared to BNC connectors. They are designed for application in various industries including aerospace, telecom and mobile applications. 50 Ω versions up to maximum 10 GHz available 75 Ω versions up to maximum 4 GHz available on request Due to the internationally standardized TNC interface dimensions a perfect 75 Ohm characteristic impedance cannot be realized *TNC = Threaded Neill Concelman / Thread Navy Connector

Rosenberger HVR®50 connectors are available in straight and angled variants. The additional slide locking mechanism (CPA – Connector Position Assurance) prevents accidental disconnection. Despite their small size these connectors achieve a current capacity of approximately 60 A at 85 °C. HVR®50 connectors are mainly used in ancillary units such as electrical heating systems, air-conditioning units, DC/DC converters, and for charging batteries.
