MagCode®

Rosenberger RPC-3.50 precision connectors, with an outer diameter of 3.50 mm, are air dielectric and include ruggedized versions. Their high specification ensures excellent performance in precision measurement microwave applications – over the full frequency range up to 26.5 GHz. They are intermateable with common 3.50 mm, SMA, K and RPC-2.92 connectors.

Rosenberger SMC subminiature coaxial connectors are for various applications up to 6 GHz. Based on a similar design to the SMB solution, the SMC’s screw-on locking mechanism provides a reliable connection for application in internal devices and cable assemblies. Please note: Rosenberger defines male – female according to the design of center contact.

The Rosenberger HPK system can achieve 275 A at 85 °C up to 1000 V. With their excellent vibration and current capacity performance the HPK connectors are well-suited to typical high-voltage electric vehicle applications such as the connection between battery, inverter and PDU. The range includes 1-, 2-, or 3-pole connectors which for maximum flexibility can be used with copper or aluminum cables in four different cable cross sections. Straight and angled cable couplers as well as corresponding headers are available, either with or without HVIL (high-voltage interlock).

With its high capacity, compact design the Rosenberger DCS is perfect for space-confined high voltage applications where direct connection is a prerequisite. With a cable cross-section of just 70 mm² the current carrying capacity is 340 A at 85 °C, making it ideal for battery charging or enabling direct connection between the battery and motor components used in electric vehicles.
