Fiber Cleaver CT50

The APM-102 perform all the steps required to prepare optical fibers before splicing – automatically and with high consistency. This includes stripping the fiber without degrading fiber quality, cleaning fiber with alcohol to remove coating residue, and cleaving consistently at a right angle to the fiber axis. The entire process is complete in as little as 23 seconds.

The Fiber holder FH-40-LT900 is exclusively designed for holding loose tube buffered fiber by Fujikura's fusion splicer,FSM-100 series, FSM-45 series, FSM-40F and FSM-40PM. The FH-40-LT900 holds the loose tube bufferd fiber by tightening a screw in the lid. The FH-40-LT900 is supplied with a pair.

The 90R12 is a mass fusion splicer capable of splicing up to 12 fiber ribbon cables simultaneously. In previous mass fusion splicer models, the v-grooves could become dirty over time due to debris and glass deposits from splicing accumulating in the v-grooves. Which in turn, could lead to fibre offsets and high losses if they were not regularly cleaned which added to the overall process time. The 90R12 comes with a first of its kind, innovative user replaceable V-groove assembly which makes this issue a thing of the past and is supplied as standard equipment with the 90R12 kit. This new V-groove assembly can be quickly and easily fitted in the field, minimizing downtime and maximising productivity. In addition, the new V-groove design enables splicing of both conventional type 12-fiber encapsulated ribbon and SWR (Spider Web Ribbon) whilst also accommodating 250um and 200um pitch fibers. The 90R12 can also splice single fibers if required. also making use of Active Blade Management Technology, which now can connect to two CT50 cleavers simultaneously.

Nyfors product. The AutoCleaver S2 is a modified version of the NYFORS automatic fiber cleaver, designed for the cleaving of air-clad fibers. It provides outstanding cleaving performance for fi bers from 125 μm up to 1000 μm in diameter. A unique and patent pending cleaving process generates typical cleave angles of less than 0.5 degrees.
