HV Fuse

Electric Vehicles (LEV) including e-bikes, e-scooters and pedelecs as well as for UGVs and drones. Providing fast and reliable magnetic connection, these are particularly suited to data communication and power transmission of voltages up to 60 V and current loads up to 40 A. The magnetic locking and precision self-mating capability prevents any accidental or forced disconnection from damaging the connector or the LEV. Furthermore, the high tolerance pin and socket design permits a large number of mating cycles. The RoPD® connection system is ideal for many LEV connection applications – including battery changing and charging – where frequent connection and disconnection is required. The four data contacts and two power transmission pins make a hot-plug capability unnecessary as the data contacts activate the power following connection. For added flexibility the data contacts can be used as a BUS system with an additional supply voltage. Versions of the RoPD® system are also available for EnergyBus applications.

Rosenberger MCX 50 Ω coaxial connectors feature a snap-on locking mechanism. They are mainly applied in RF cable connections up to 6 GHz such as those found in fixed and wireless communication systems. MCX connectors offer high reliability, long service life, as well as easy and fast mounting. The PCB connectors are supplied in tape and reel packaging for automatic assembly to boards and in blisters. MCX connectors with 75 Ω characteristic impedance are available on request.

Rosenberger QN coaxial connectors are based on the N connector interface. With a frequency range of up to 11 GHz depending on the connector and cable type, the quick-lock mechanism enables reliable and easy connection, 10 times faster than standard N offerings. Ideal for tight spaces such as those found in mobile base stations, the packing density of QN exceeds that of N connectors due to the minimum pitch and toolless assembly. Torque spanners are not required. QN and standard N connectors are not intermateable.

SMP subminiature connectors are well-proven, offering a high level of flexibility in alignment tolerances and simplifying the whole production process. Rosenberger SMP connectors are suitable for a wide range of board-to-board and cable-to-board applications up to 40 GHz. Such a broad frequency range allows from the lowest to the highest mechanical loads to be handled including those experienced in 5G mobile telecommunications, test & measurement and aerospace applications.
